Maintenance

For Passat / Passat Variant

Original Volkswagen repair manual


10,05 €7% VAT incl.

Immediately available for download

Language: English

Digital PDF file

1.824 KB

109 Sites

Detailed technical data

Immediately readable

This repair manual contains: Engine list, Service work, General, Descriptions of work, Exhaust emissions test and Glossary. Show more
Secure Payment via PayPal, credit card, direct debit and more
PayPal Logo SEPA Lastschrift Logo Giropay Logo Sofort Überweisung Logo

Repair manual Passat / Passat Variant Maintenance PDF download has the following content:

Chapter overview

  • 1 Engine list
    1
  • 2 Service work
    4
  • 2.1 Service tables
    4
  • 2.2 Oil change service
    5
  • 2.3 Inspection service
    6
  • 2.4 Time or distance dependent additional work
    11
  • 3 General
    14
  • 3.1 Raising vehicle with lifting platform and trolley jack
    14
  • 3.2 Sticker
    15
  • 3.3 Connecting fault reader
    15
  • 3.4 Vehicle identification number
    18
  • 3.5 Countries with elevated sulphur content in diesel fuel
    18
  • 3.6 Engine code and engine number
    19
  • 3.7 RME fuel (biodiesel) for vehicles 1996▸
    19
  • 3.8 Type plate
    20
  • 4 Descriptions of work
    21
  • 4.1 Driver and front passenger airbags: Visual check of airbag units
    22
  • 4.2 Self-diagnosis: Read fault memories of all systems
    22
  • 4.3 Door arrester and securing pins: Grease
    26
  • 4.4 Sunroof: Check function, clean and grease guide rails
    26
  • 4.5 Windscreen wash/wipe system and headlight washer system: Check function
    27
  • 4.6 Windscreen wiper blades: Check park position, if wiper blades judder: Check setting angle
    30
  • 4.7 Checking tyres: Condition, wear pattern, inflation pressures and tread depth
    32
  • 4.8 Oil level: Check
    34
  • 4.9 Engine oil: Drain or extract, renew oil filter and fill with oil
    35
  • 4.11 V-belt (power-assisted steering vane pump): Check condition and tension
    38
  • 4.13 Manual gearbox/final drive: Check oil level
    40
  • 4.14 Rear final drive (syncro): Check oil level
    40
  • 4.15 Automatic gearbox: Check oil level of final drive
    40
  • 4.16 Brake system: Perform visual check for leaks and damage
    42
  • 4.17 Front and rear brake pads/linings: Check thickness
    43
  • 4.18 Underbody protection: Perform visual check for damage
    44
  • 4.19 Track rod ends: Check play, security and boots
    44
  • 4.20 Swivel joints: Visual check
    45
  • 4.21 Cooling system: Check frost protection and coolant level
    45
  • 4.22 Spark plugs: Renew
    47
  • 4.23 Dust and pollen filter: Renew filter element
    48
  • 4.26 Camshaft drive toothed belt (petrol engine): Check condition and tension
    49
  • 4.27 Toothed belt: Check for wear (TDI engines)
    49
  • 4.28 Fuel filter: Renew (diesel engine)
    50
  • 4.29 Fuel filter: Drain water (diesel engine)
    51
  • 4.30 Automatic gearbox: Check ATF level
    52
  • 4.31 Automatic gearbox: Change ATF
    58
  • 4.32 Power-assisted steering: Check oil level
    61
  • 4.33 Changing brake fluid
    63
  • 4.34 Brake fluid level (dependent upon lining/pad wear): Check
    65
  • 4.35 Battery: Check
    66
  • 4.36 Engine basic setting (petrol engine with engine code 2E): Perform
    66
  • 4.37 Idling speed (diesel engine with engine code AAZ): Check
    70
  • 4.38 Headlight adjustment: Check
    71
  • 4.39 Road test: Perform test
    74
  • 5 Exhaust emissions test
    75
  • 5.1 Exhaust emissions test for petrol engines
    75
  • 5.2 Exhaust emissions test (EET) for diesel engines
    98
  • 6 Glossary
    104
Manufacturer's designation Maintenance
Manufacturer Volkswagen
Suitable for Passat / Passat Variant (1994 - 1997)
Suitable car types 3A
Category Wartungsanleitung

There are no reviews for this product at the moment.
